DC SPD Surge Protective Device 3P 1000V

The product features of the solar surge protection device are as follows.

Maximum continuous working voltage (UC) 1000V.

Protection class（KV）3.6.

Withstand current (8 / 20μs) In（KA） 20.

Maximum withstand current (8/20μs) Imax (KA) 40.

Response time (ns) <= 25.

Working environment -40℃～80℃.

Electrically insulated PBT sheath material with added fibers.

Installation method DIN 35mm pinion rail.

Standard EN50539-11.

Utilizes the latest heat dissipation technology There is built-in thermal protection in the device and the device automatically shuts down when there is a short circuit. Completely avoid the fire.
